Alco-Sensor RBT IV Evidential Breath Testing Systems
Questions? Speak with a specialist!



The Intoximeters Alco-Sensor RBT IV for DOT testing is the most widely used instrument available and is ideal for workplace alcohol testing programs.
- Approved by the U.S. DOT as an Evidential breath alcohol tester
- Great for Regulated and Non-Regulated workplace testing programs
- Evidential accuracy exceeds +/- .005 at .100 BrAC
- Lightweight and portable for on-site testing
- Easy, straight-forward test protocol with no unnecessary data input make for a faster testing sequence
- Exceptional accuracy and durability
- The hand-held Alco-Sensor IV connects to the battery-powered RBT IV printer to produce a totally portable DOT-compliant alcohol testing system
- Alco-Sensor IV and RBT IV printer displays prompt the operator through a DOT test procedure, reducing operator error
- A Screening test of .020 or greater triggers an automatic 15-minute countdown on the RBT IV printer display
- Following a positive Confirmation test of .020 or greater, the RBT IV printer further prompts the operator to perform an Accuracy Check
- RBT IV printer function keys start common testing procedures by pressing a single button: Screening test, Confirmation test, Calibration Adjustment, and Accuracy Check.
- Automatic and manual breath sampling capability
- Waterproof Pelican case protects the instrument and printer from extreme weather and rough treatment
- A 12 volt rechargeable battery powers the RBT IV printer and maintains its charge for up to 50 tests
- Printer cables and battery connections are secured under the foam cut outs within the case
- RBT IV printer prints results on tamper evident printer paper or 3-ply paper
- Easily and quickly conduct monthly Accuracy Checks and, if needed, Calibration Adjustments
Sensor type | Electrochemical Oxidation (fuel cell) |
Range of measurement | .000 – .400 BrAC |
Accuracy and precision | U.S. DOT approved for evidential use |
Breath sampling | Automatic with manual override |
Response time | 5 – 10 seconds negative results, 10 – 30 seconds positive results |
Power requirement: ASIV | 9-volt battery (included), 300+ tests |
RBT IV Printer | 12-volt rechargeable battery, 75+ tests |
Test mode | Direct |
Calibration | Microprocessor controlled, using dry gas or wet bath simulator |
Memory: Alco-Sensor IV | last test |
RBT IV printer | 900 tests, upload to computer with adapter |
Print capability | Yes, single-ply paper, triplicate results |
Temperature range | 0 to 40 degrees C |
Size | 12″ X 9″ X 3 , 12 lbs (in Pelican case) |
Warranty | Two years parts and labor |
