RespSense WideScreen - Handheld Capnograph - RESP HUMAN-01

This product may require 7-10 business days to process and prepare for shipping.

• Meets rigorous ISO requirements for EMS transport
• Numerical EtCO2 and respiratory rate display
• 1.5 Hours trending of EtCO2 and respiration rate
• Backlit LCD Display
• TrendSense memory module (72 hours of data), download cable and software
• TrendSense memory module with waveform (36 hours of data and capnogram waveform), download cable and software
• Data output via RS-232 port
• Capnography measuring data - 3 to 80 respirations/min respiration range; once every breath (no breath alarm after 25 sec) update frequency; 3 to 50 respirations/min ±2, 51 to 80 respirations/min ±5 respiration accuracy; 0 to 99 mmHg or 0 to 9.9 kPa EtCO2/CO2 range, ±0.2 kPa/±2 mmHg EtCO2/CO2 accuracy, +6% of reading (EtCO2 /CO2 reading reaches its steady state accuracy 10 minutes after power up); 1.5 hours trend length
• 0 to 40°C Operating temperature
• 10 to 90% Noncondensing operating humidity
• 645 to 795 mmHg atmospheric pressure
• Pump - 75 mL/min Pump flow; ±15 mL/min flow accuracy
• Battery data - lithium-ion internal battery type, rechargeable; approximately 8 hours battery capacity; approximately 17 hours or 2 hours for each hour of use charging time
• Power data - 100 to 240 VAC, 50 to 60 Hz battery charger; 3.6 W at battery operation, 9 W with power supply power consumption; 12 VDC, 720 mA input
• 2 X 5.3 X 7.9 Inch Dimensions

Stock Number : 802281

Manufacturer # : RESP HUMAN-01

Brand : RespSense WideScreen

Manufacturer : Nonin Medical

Country of Origin : Unknown

Application : Handheld Capnograph

UNSPSC Code : 42271503

MONITOR, CAPNOGRAPHY RESPSENSEW/STD ACCESS
